Rewritable Laser System Key Specifications

Menu

Product appearance

Product Specifications

Rewritable Laser Marker

Laser Laser output Printing Class 4 30W
Erasing Class 4 125W
Wavelength 918nm
Printing/erasing area 110mm
Print contents Characters Double-byte character：Alphanumeric, Hiragana, Katakana, Symbol,
Kanji (JIS 1st and JIS 2nd level), IBM extended characters
Single-byte character：Alphanumeric, Katakana, Symbol
Decorative characters Bold characters, Reverse characters, Open face characters
Character size*1 2mm～30mm
Barcode type Type 代码39、代码128、ITF、NW-7、GS1-128
Barcode data capacity Up to 46 digits
Two-dimensional code type Type QR code (model 2)
QR code data capacity Maximum 300 characters (Kanji)
Printing time Depends on data amount
Erase time*2 2.1 seconds
Line width*3 0.25mm
Interface Data communication Network 10/100BASE-TX/1000BASE-T, Socket communication
Character code UTF-16
Control Terminal type Round crimp terminal
Standard work distance 114mm
Work distance variation range With position compensation*4 114mm±10mm
Without position compensation 114mm±3mm
Power consumption 395W
Power supply voltage Printing 160VA±30VA
Erasing 450VA±50VA
等待 120VA±30VA
External dimensions Head unit W:162mm D:330mm H:280mm (excluding protrusions)
Laser unit W:250mm D:430mm H:350mm (excluding protrusions)
Controller unit W:200mm D:430mm H:350mm (excluding protrusions)
Fiber optic tube length
(distance between head unit and laser unit)		 2.0m±0.2m
Weight Head unit 18.5kg±0.5kg
Laser unit 14.5kg±0.5kg
Controller unit 12.0kg±0.5kg
Operation temperature 0℃～35℃ (without condensation or freezing)
Operation humidity 30%～80% (without condensation or freezing)
Noise Less than 80db
Standard (radio safety, product safety, laser safety) IEC61010-1:2010
IEC60825-1:2014
  • *1Indicates the range of character size that can be set. Due to printing conditions, small characters may not be reproduced sufficiently.
    Recommended font size is 4mm or more.
  • *2型媒体抹去在22℃。时代e time varies depending on the operation temperature.
  • *3Reference only. May vary depending on printing condition.
  • *4With the distance correction function activated.
  • *Product specifications may change without notice. Last update: July 22, 2020.

Rewritable Laser Media

Classification Item Specification Test method
Basic properties Thickness (including liner) 297±30μm Ricoh test method
Base material PET -
成像/擦除属性 Imaging color Black Visual inspection
Background density 0.25 Maximum Ricoh test method
Image density 1.1 Minimum
Density after erasing Background density +0.03 Maximum
Image preservation properties Light resistance Density after printing 1.1 Minimum
Density after erasing Background density +0.03 Maximum
Water resistance Density after printing 1.1 Minimum
Density after erasing Background density +0.03 Maximum
Adhesive properties Low temperature (at 5℃) 5N / 25mm minimum Ricoh test method
High temperature (at 60℃)
Cleaning solution resistance (70℃ alkali/neutral solution)
  • ●Warranty unit：1 box
  • ●Operation conditions：5～35℃、30～85％ RH without condensation
  • ●Storage conditions：Store indoors (0～40℃, 30～85% RH, without condensation), avoiding direct sunlight and humidity
  • ●Warranty period：For unopened products stored under the storage conditions mentioned above, this product specification shall be guaranteed within 12 months after shipment from Ricoh
  • *Product specifications may change without notice. Last update: July 22, 2020.
